ONE (1) ABB-HITACHI 242KV SF6 2000AMP CIRCUIT BREAKER

Reconditioned ABB-HITACHI 242KV SF6 Circuit Breaker Type: 242 PA 40-20 Max Voltage: 242 KV Short Circuit: 40 KA Freq: 60Hz Impulse Withstand: 900KV Interrupting Time: 2 Cycles Continuous Current: 2000A Voltage Factor "K": 1.0 Transient Overvoltage: 2.0 Line Charging Currnet: 200A Isolated Shunt Cap Bank Current: 400A Back To Back Shunt Cap Bank: 400A Transient Inrush Peak: 20KA Transient Inrush Freq: 4250Hz Out of Phase Switching: 10KA *Additional Information on Provided Nameplate*

Learn More

Reconditioned ABB-HITACHI 245KV SF6 Circuit Breaker

Type: 242 PA 40-20

Max Voltage: 242 KV

Short Circuit: 40 KA

Freq: 60Hz

Impulse Withstand: 900KV

Interrupting Time: 2 Cycles

Continuous Current: 2000A

Voltage Factor "K": 1.0

Transient Overvoltage: 2.0

Line Charging Currnet: 200A

Isolated Shunt Cap Bank Current: 400A

Back To Back Shunt Cap Bank: 400A

Transient Inrush Peak: 20KA

Transient Inrush Freq: 4250Hz

Out of Phase Switching: 10KA

*Additional Information on Provided Nameplate*
